10 inches from this one, so as to form a gutter waterway and a stop for the wood deck. The whole of the main deck beams are plated over with steel, under the wood deck, the two center line strakes being of I0 pounds, and the remainder of 8-pound material. The main deck is of pitch pine 4% inches… … between centers, and are of angle steel 3 by 2'%4 inches by 6/20 inch, extending in one length, from keel to underside of main deck, except in wake of the deck erections, where they are, where practicable, carried to the under side of upper deck. Heel pieces are fitted at the center line, for 2…
