An introduction to machine sketching and drawing for industrial and technical schools (1917)
Toronto : Copp, Clark · leaf 60
[57] 58 MACHINE SKETCHING AND DRAWING DEcisrAL Equivalents 1 1. 1/32 .0313 1/64 .0156 33/64 .5156 1/2 .5 3/32 .0938 3/64 .0469 35/64 .5469 1/4 .25 5/32 .1563 5/64 .0781 37/64 .5781 3/4 .75 7/32 .2188 7/64 .1094 39/64 .6094 1/8 .125 9/32 .2813 9/64 . 1406 41/64 .6406 3/8 .375 11/32 .3438 11/64 .1719…Mechanical drawing
Internet Archive · Western University Libraries · Public Domain Mark 1.0. Free to use for anything.
