, frame; B, carriage; C, gun stock; D, former; E, cutter-head; F, guide wheel; G, swinging frame; H, feed motion;K, shaft for revolving stock and former. TURRET LATHES 97 cutting wheel, and a friction wheel, equal in diameter. The cuttingwheel turns on a horizontal axle, and bears on its periphery… … Turret lathe: an early Brown & Sharpe model. C, carriage; T, turret; L, hand lever; F, face plate; D, jaw chuck; E, tool. recede from this friction wheel; the cutting wheel in its corre-sponding motion removes wood from the block until a duplicate ofthe pattern appears. This lathe much…
