Inventors at work, with chapters on discovery (1906)
Iles, George, 1852-1942 · New York, Doubleday, Page & company · leaf 389
ich reststhe stem of valve 11. Owing to the suction in chamber 9 thisdiaphragm instantly raises and shuts the outer port 23 by meansof valve 11, giving a free communication from pipe 8 throughchambers 9 and 12, to the striking pneumatic 13 which collapses,and through pitman 19 and finger 20 strikes… … Schumanns Traumerei, first notes. and the pressure on the small diaphragm in chamber 9 has ceasedto be operative, and valve 11 immediately drops and allows air to * \. /i • \ Ped.,*(a) Ped. 1 <*::: • ° ... . ! i MF 3 Beginning of Roll. •») XV } w P«o 2 1 (a) Ped. puton damper pedal; •& take…
