Johnson's natural philosophy and key to philosophical charts : illustrated with 500 cuts; being reduced photographic copies of all the diagrams contained in the author's philosophical series of indestructible school charts ; for the use of schools and families (1878)

Johnson, Frank G., 1835- · Chicago, A.H. Andrews · leaf 200

An illustration from Johnson's natural philosophy and key to philosophical charts : illustrated with 500 cuts; being reduced photographic copies of all the diagrams contained in the author's philosophical series of indestructible school charts ; for the use of schools and families, 1878, leaf 200
nycontrivance for converting heat into mechanical energy through themedium of water. The first rudiments of knowledge of steam as a motor date back ofmodern times. As early as 130 years before the Christian era, Heirodescribes, among other curious contrivances, the eolipile. 346. Figure 38.—The… … project two other arms, at the ends ofwhich, on opposite sides, are openings forsteam to escape. In the boiler is water,which is converted to steam by heat. Thesteam passes into the cross-bar, where itcomes in contact with the side-arms of theboiler, and escapes at the openings, asshown. The…
