Fig. 37. Uuiver.sal Gainer Mechanism. rides, or leaving spaces between, forming one compact, uniformpackage from start to finish. The weight q holds the belt underuniform strain to insure accuracy at all times. The gear pinion wand the gear u are enclosed in a casing and run in oil, thus assuring… … KNITTING 93 durability and requiring less power. The top shaft a is oiled bymeans of the reservoir in the top of the frame, which automaticallycarries the oil through the bearings and returns it to the reservoir. The threading of the machine aid the arrangement of thetension is shown at Fig. 38,…
