Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)

American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 121

An illustration from Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care, 1909, leaf 121 — lever e and a movable weight j on the lever. To increase thepressure of the guide against the cone, move the weight y toward dieouter end of the lever. The softer and finer the yarn, the less pressureis required, and for knitting yarn, the pressure should be reducedto the least quantity. Adjusting… … Fig. 38. Universal Differential Tension Mechanism. 108 KNITTING 95 and sufficient tension placed vipon it to keep it in line for uniformdelivery to the cone. On the lever h, which is connected to themovable tension blade d by means of the link i, is a weight h, whichcan be shifted to increase or…

Knitting machines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
