Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 137
formed, the channel in the plunger can be rested on the latch,the plunger having been drawn up beyond the trip. In this position,it does not interfere with the running of the machine in any way, but.should a lump gather on the needles, or some other imperfectioncause a needle to rise .slightly… … KNITTING 109 In Fig. 52, B represents the cam ring of the knitting frame, Cthe cyhnder and F the diaL Y*^ is the cast-iron bracket fastened tothe cam ring by screws through the angle post; Y is the phmger inwhich is cut the recess or channel Y^, into which one end of the swivelbar Y rests in its…
Knitting machines
