Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 154
Fig. (57. Plain Machine with Fabric Roll in Place of Can. K. The thread guides L are fixed to the stationary cam dial in amanner to properly present the thread to the needles at points wherethe dial needles are operated by the cams. 138 … KNITTING 125 The bevel gear ring D receives its motion from the spur gear D,which is fixed to the driving shaft D^ (See Fig. 61) and on which aretight and loose pulleys. The shaft D is mounted at the inside endin a bearing in the right housing plate, and at the outer end in a bear-ing in the…
Knitting machines
