Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 190
Racked Courses. sion A to furnish bearings for the main shaft, which is provided withtight and loose pulleys, and has a bevel gear, or pinion, which engagesthe teeth of the dial cam plate A* to rotate it. The bolt A^ on theyoke A enters a link A, wdiich is pivoted on an arm A^^ projectingfrom the… … KNITTING 155 ing from it is the central shaft A^ (See also Fig. 94), having the attach-ed collar A on which rests the hub of the large ring-like washer Bloose on the shaft. The needle cylinder B^ is supported on the
Knitting machines
