Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 192
KNITTING 155 ing from it is the central shaft A^ (See also Fig. 94), having the attach-ed collar A on which rests the hub of the large ring-like washer Bloose on the shaft. The needle cylinder B^ is supported on the … Fig. iil. Sweater and Cai-digau Jacket Machine. washer B, and prevented from rotating with the shaft by its projectingrib a engaging the fork B^. When the cam plate is rotated, the hubcarrying the cams turns in unison with it and the needles in the sta-tionary cylinder are thereby actuated to form…
Knitting machines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
