f the Acme type. Fig. 132, comprisesa stationary needle cylinder, an encircling rotating cam cylinder, andlatch needles with butts or lateral projections in their shanks. Theneedle cylinder has a series of longitudinal, parallel grooves on itsouter surface, and the cam cylinder is provided with… … cylinder revolves, the butts come in contact with and slide up and downthe inclines or cams, and so cause the requisite up-and-down move-ment of the needles in the operation of knitting. Operation. The needle is lowered to knit, by what is called thestitch cam, which has a diagonally inclinededge,…
