Knitting; a manual of practical instruction in the mechanical details of all types of knitting machinery, their operation, adjustment, and care (1909)
American School of Correspondence, Metcalf, M. A. [from old catalog] · Chicago, American school of correspondence · leaf 259
isrotated and also by reason of the inclined portions of the cylinder bot-tom, allows the cylinder to descend by gravity, thus shortening thestitch and reducing at the desired place the size of the stocking. Aguide blockr^ (See also Fig. 136), which is fastened in the cylindereuide and extends into… … KNITTING 217 er by the addition of the ring a^ to its interior. The ring is fastenedto the cyhnder with a screw 4 and has a projecting ledge a? whichsupports the jack support-ring a?, which is in turn secured to thecyUnder by means of the screw 5. The jack supporting ring is slottedon the top edge…
Knitting machines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
