Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 112

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 112
ORIGINAL HIGH ROLL CUT-MOTION FOR EMODEL LOOM. The cut illustrates our earliest pattern of High Roll cut-motion. It was quickly superseded bv the next type shown. I05 … DETAIL OF THE CLOTH WINDING DEVICE ORCUT-MOTION ON OUR HIGH-ROLL TAKE-UP. This is the cut-motion which has been an integral part of thegreater number of Northrop Looms sold. It has ]:»een univer-sally satisfactory on the average line of goods. Certain cloth,however, requires greater chance to yield…

Looms

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
