Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A. (1904)

Draper, George Otis, 1867-1923 · Milford, Mass. : Printed by Cook & sons · leaf 54

An illustration from Labor-saving looms : a brief treatise on plain weaving and the recent improvements in that line, with special reference to the Northrup looms manufactured by Draper company, Hopedale, Mass., U. S. A., 1904, leaf 54
PERSPECTIVE VIEW OF EARGE HOPPER, ORIGI-NAL DESIGN. Taking- the various attachments in order for detailed consid-eration, we shall consider the Hopper tirst, as the more import-ant element of the \vhole combination. The cut shows theLarge Hopper, or ^24-Bobbin Hopper. It is operatedin rotation by… … LKATIlKIl\VASH1.R pi()\ iclctl with a leather washer cushion to pre\ent breakage,and \vc are also iisinii^ a new form of bobbin tip holder,which will take either bobbins or cops, as desired. We start-ed with a hopper that held a sup]:)l\ of 14 extra bobbins,but the change to the 24-b()bbin hopper…
