La operazione del compasso geometrico, et militare (1640)
Galilei, Galileo, 1564-1642 · Padova, P. Frambotto · leaf 81
adivn fiume venendo fopra la ripa, ò altro luogo eminente ,ficomeinell'effem pio fivede, nel qual volendo noi mifuraf la larghezza CB. venendo nel pun- to A. traguarderemo conla cofta AF. l'eftremità B. no- , tandoipunti DE. tagliati del perpendicolo , quali fiano verbi gratia 5.8 quante volte…
Compasses (Mathematical instruments) · Measuring instruments · Geometry -- Early works to 1800
Internet Archive · Fisher - University of Toronto · Public domain (published before 1931). Free to use for anything.
