eedle are also given in each case. 186. Directions for Setting up Students Combina-tion Galvanometer.— Seat the detector galvanometer on the horizontal support of thecoil frame, Fig. 158, by means of the projecting wooden pin. Turnthe frame so that it points N and S, with its plane in the… … n Parol I.J B. Two Coils in Ser,« itr, C All Coils Two in Parallel - 6 Turn. 2 Tur... Fig. 160.—Connections of Coils in Students Tangent Galvanometer. vanometer on its wooden pivot so that the zero position on thescale lies directly underneath the pointer. Send a current throughthe four coils in…
