Lessons in practical electricity; principles, experiments, and arithmetical problems, an elementary text-book (1903)
Swoope, Coates Walton. [from old catalog] · New York, D. Van Nostrand company · leaf 384
351.—The Act of Commutation of anArmature Coil. At the instant shown coil B is short-circuited bythe brush. * Suppose that the brush in Fig. 351 had been made of copper instead of carbon, as isgenerally used, its resistance would have been less and a greater current would havecirculated around the… … Fig. 352.—Brushes Set Diametrically Opposite on the Commutator of a Bipolar Dynamo. point, and the E. M. F. in them is higher, causing a greatercurrent to rise for the instant, which is noticed by an in-crease in sparking at the brushes. To find the neutral, ornon-sparking point of a dynamo, ivhen…
Electricity · Magnetism
