ferenceacross any branch by the current flowing through any branch,according to Ohms Law. Prob. 62-A : Find the current through each branch of the dividedcircuit in Fig. 119, if the potential difference is 24 volts. By II 161 C = |^~== 12 amperes. 94 04 Also ^r- = 6 amperes and ~ = 3 amperes. 162.… … lion of the total current may be passed through the galvanometer, the remainder passing through the wire, S, connect <,across the galvanometer terminals. The wire, S, forme a by-path for the current, and bcalled a shunt, and the galvanometciis said to be shunted. If the resist-ance of the…
