s of wire to providesufficient exciting power to drive the lines of force throughthe air. To obtain a gentle pull over a long range, asolenoid or long tubular coil and a long movable core is used,as in Figs. 175, 177, and Xo. 6 and 11 of Fig. 181. Fornearly all purposes the iron parts, including… … Fig. 183.—Electromagnet withthe Oil on the Yoke.
