Lessons in practical electricity; principles, experiments, and arithmetical problems; over four hundred illustrations; an elementary text book (1909)
Swoope, C. Walton (Coates Walton), d. 1901 · New York, D. Van Nostrand company · leaf 271
3 and 4, no currentflows through the galvanometer, consequently its needle re-mains at zero. If a piece of heavy wire were connected topoints 3 and 4 under these conditions, no current would flowthrough it, nor would the current in the circuit be disturbed.If after a balance is so obtained the… … MEASUREMENT OF RESISTANCE. 253 is less than 2 volts, while that between a and 3 is 2 volts.If, in the same manner, the slider at 4 is moved toward d,there is a greater drop across c—4 than a-3, and the currentat 4 divides, part flowing to point 2 by 4-3 through thegalvanometer, and deflecting its…
Electricity · Magnetism
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
