Fig. 88.—Elements of a Carbon Cylinder Cell.Zinc, carbon and sal-ammoniac solution. BATTERIES. 73 cell of the Standard Carbon Co., in which the carbon is madein the form of a porous cup and then filled with oxide ofmanganese to prevent polarization. Still another form of thesame make is shown in… … .big. 8y.—Elements of Carbon Cylinder Cell with Depolarizer.Zinc, manganese dioxide in a porous cup and sal-ammoniac solution. manganese and then sealed in. The zinc rod is prevented fromtouching the carbon by being first inserted through a porce-lain insulator. About 4 to 6 ounces of sal-ammoniac…
