iver. The break in the flange D, Fig. 5, followed regularly the line of theinner circle of rivet holes by which it was secured to the wrought-iron gore pieces. Thegore pieces were separated from each other on diverse lines of rupture, Fig. 2. — somethrough the sound plates, others partly on the… … -6 <<. Fig. 2. was not entirely along the girth seam, but the line of ruptureextended in four places into the sheets of the shell, Fig. 3,separating as many triangular pieces, which remained attached to the adjoining gores, and in one instance into the zone, leaving a triangular piececomposed…
