s.) diameter,and two safety-valves of 85 mm. (3^) diameter, as shown in Fig. 3. The feed apparatus was the same for all boilers, there being two pipes with check-valves in front of each boiler, in the ordinary manner. The flues were arranged as they usually are with boilers of this type. At the… … wall, causing boilers ISTos. 22, 23, and 1 to 7 inclusive, to discharge into the northernstack, and 8 to 20 into the southern one. (See Fig. 1.) 84 THE LOCOMOTIVE. [June, The boilers were all fired by high furnace gases, distributed from an iron pipe toall in the same manner, by smaller vertical…
