structive center was not only inside of theboiler tube, but also inside of this piece of \\-inch pipe. A glance at Fig. 1 will satisfythe reader of this, and the fact is still more evident when the pipe itself is examined atfirst hand. Some of the fragments shown in Fig. 6 came from this pipe, as… … Fig. 9. flash-light pnotogkaph of interiorop Boiler. 150 THE LOCOMOTIVE. [(>( Tor.KR, the flash-powder being inserted and fired through the hand-hole. The picture soobtained is shown in Fig. 9. The lower row of tubes was driven to the bottom ofthe shell, and the other tubes had all been blown…
