Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 27
Lower Telescope Tube Spring. 66 Bottom Flexible Wire. 96 Upper Insulation fibre. 67 Top Flexible Wire. 96* Lower 1 nsulation Fibre. 68 Binding Post Screw. 97 Insulation Washer. 69 Top Lever Screw. 97* Brass Plate. 70 Bottom Guide and Tube. 98 Vertical Adjusting Screw. 71 Middle Telescope Tube. 99… … Fig. 4. Electric Headlight—Lamp C. LOCOMOTIVE APPLIANCES. 19 will flash and go out, for the magnet will be drawndown too far. When the light goes out the current isbroken, and there being no strength in the magnet,the spring will again bring the carbons together,then the current is instantly…
Locomotives
