Kirkman, Marshall M. (Marshall Monroe), 1842-1921 · New York and Chicago, The World railway publishing company · leaf 95
how n in the engra\ ings. 86 LOCOMOTIVE APPLIANCES. Any couplings used by any railroad can be usedwith the joint the same as if it were hose. This conduit has been adopted by a number of thelarge railway systems of the country. CLIMAX FLEXIBLE METALLIC JOINT. Fig. 1 shows the general construction… … Fig. 1.Climax Flexible Metallic Joint. Fig. 2 shows a sectional view of one of the universaljoints. They are made entirely of steam metal, andthe two glands (G-G) are each surrounded by threeJenkins discs screwed down to a joint by the nuts(E-E). These nuts have holes in their faces to per-…
Locomotives
