Locomotive breakdown questions answered and illustrated (1907)
Wallace, W. G · Chicago, F. J. Drake & Co. · leaf 32
^ … U V —t^-* Fig. ». PUJn D Slide Valve Fig. 2. BaUncc Valve. to its seat at all times when the throttle is open, and theexhaust steam and the steam pressure in the cylinderwhen the valve has just closed the steam port or cut-offthe steam forcing it up from its seat. The area of thevalve being the…
