Locomotive engine running and management .. (1899)
Sinclair, Angus, 1841-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 287
rly set up to hold the driving-boxes in about the 238 LOCOMOTIVE ENGINE RUNNING. same position they will occupy when the engine is atwork. CONNECTING ECCENTRIC-RODS TO LINK. In looking over the motion, it is well to note thatthe eccentric-rods are properly connected,—the for-ward eccentric-rod with… … Fig. 15.are open, and nearly horizontal. The full parts ofboth eccentrics are advanced towards the crank-pin,so that the centers of the eccentrics are advanced froma perpendicular line drawn through center of axle, ahorizontal distance equal to the lap and lead. Whenthe crank-pin is on the back…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
