Locomotive engine running and management .. (1899)
Sinclair, Angus, 1841-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 375
Fig. 42. Fig. 43. into the smoke-box, which impairs the efficiency ofthe pumping action. Although in these illustrations I have used only theopen stack, the defects pointed out apply equally wellto engines having low nozzles, petticoat-pipes, anddiamond stacks. EXHAUST-PIPES AND NOZZLES. The first…
Locomotives
