Hill, John A. (John Alexander), 1858-1916, Sinclair, Angus, 1841-1919 · New York : American Machinist Pub. Co · leaf 12
[MPROVLD STEAM GAVGE. pipes inside the gauge—one great troublewith the brazed tubes. Then the gear andsegment were so arranged that, when ad-justed to the proper working pressure, allwere perpendicular and in line, with nostrain from weight of parts, etc. There isno connection to back of gauge at… … AM liAUGE. gear and working parts are supportedon the central connection of bent tube;the case merely surrounds it, and is nonecessary pari of it to Insure true results.The gears are cut by watch-making ma-chinery and have wide faces, to preventwear. Around the gauge casing front is adeep groove…
Railroads · Locomotives
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
