Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 16
PE RFECT. Figs. 3 and 4 show side and end views of the fire ina nearly perfect condition. It will be noted that the LOCOMOTIVE FIRING. fire is slightly heavier at the sides and ends of the fire-box than in the center, and it should be kept in thiscondition, as there is more air admitted at the… … S&-*-
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
