Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 220
the tire, making allowance for set-tling, the cellar removed if possible, a block fittedin place of the cellar and a block placed betweenthe bottom of the driving box and the top of thebinder. If the cellar cannot be removed, a nut shouldbe placed on top of the binder under each jaw ofthe driving… … PLATE 86. 2IO BREAKDOWNS. removed is, that if a block were placed on top of the bind-er the full width of the driving box, there being moreweight on the driving box than on the cellar, and thecellar having more surface on the blocking than the driv-ing box width, the driving box would gradually…
Locomotives
