Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 296
PLATE 128. PLATE 129. A feature in the construction of this superheater isthe T-pipe, the regular conventional T-pipe being replacedby one of special design, shown in Plates 128, 129 and130. This T-pipe is subdivided into two compartmentsby a horizontal partition, and extends nearly across…
Locomotives
