Locomotive text for engineers and firemen; a complete treatise on the engine, electric head-light and standard code of train rules (1908)
National correspondence school of railroading, Chicago. [from old catalog] · [Chicago] · leaf 58
48 LOCOMOTIVE INJECTORS. usually placed in a convenient position inside the enginecab, and about six inches above the highest water levelin the tank, and is connected with the elbow at the backof the injector by means of a pipe, which must be of thesize called for by the overflow connection. The…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
