= 655. S2 — 791 lb. per square inch, which shows that the sectioncould be materially reduced in size if it were desired. Thereduction could very properly be made according to the dottedlines. If it were considered necessary, this section should also beinvestigated for compression. To investigate… … Fig. 136. 145. Having determined several important sections in theframe, the outline of the G part of the frame can be drawn. Thisoutline will of course be modified somewhat for the shaft, headand leg. It will be noticed that a somewhat.higher fiber stress has beenallowed in the material for this…
