Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 11
screws,pulleys, cams, gears, etc. Finally, complete detailed drawingsare furnished and exhaustively discussed in connection with thedesigns of a duplex pump and of a direct-current generator.The presentation is exceedingly practical and will appeal to menwho are interested in either the mechanical… … GISHOLT TOOL GRINDER Courtesy of Gisholt Machine Company, Madison. Wisconsin MACHINE DRAWING PART I WORKING DRAWINGS METHODS AND CONVENTIONS In Mechanical Drawing, Parts I, II, and III, the commondrafting instruments and materials are described, and hints givenregarding their use; the fundamental…
