Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)
Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 121
ylinders, asexplained in Mechanical Drawing, Part III. The limitations of construction of cylindrical cams are consider-ably greater than those of the simpler rotating cams; and it is morefrequently a question of experiment and trial to get the proper sur-faces, than it is of exact theoretical… … Fig. 93. Diagram of Simple Open Belt Drive centers of shafts increases, the driver and follower for such methodsof transmission become large, unwieldy, and costly, and rigid linksmay be used to connect the rotating pieces, as in the case of parallel MACHINE DRAWING 109 rods of a locomotive. For a…
Machinery
