Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1920)

Griffin, Charles Lewis, 1867- [from old catalog], Adams, Charles Clyde, 1882- [from old catalog] joint author · Chicago, American technical society · leaf 20

An illustration from Machine drawing, a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator, 1920, leaf 20 — Fig. 13. Location of Shade Lines forRounded Corner … Fig. 14. Location of Shade Lines forCircular Piece

Machinery

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
