Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 109
t surface, its path being perpendicular to itsworking face. The length of its path 06 is the same as before, andis divided into six equal divisions. 96 MACHINE DRAWING 2. Cam Radii. The point of original contact 0 being chosen,the original radius OC is drawn .perpendicular to it; the radii CXand… … Fig. 85. Diagram of Cam with Flat Follower Perpendicular to Working Face of the rotating arcs with the several positions of the radii, are foundas before. The rotated positions of the follower in this case areobviously represented by drawing perpendiculars to the several radiithrough the points Rv…
