Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 111
with these radii as 98 MACHINE DRAWING the follower in its corresponding positions makes with the originalradius CO. For example, the angle at is equal to a; the angle bt isequal to b; and the angle c2 is equal to c. 4. Tangent Line. The tangent line is now drawn to the severalpositions of the… … Fig. 86. Diagram of Cam with Flat Follower on Oscillating Arm as in Fig. 85, and it is suggested that the rotation of them back to thepositions of the follower in its path be accomplished by the tracing-cloth method, as in Fig. 83. Design of Complicated Cams. It should be especially noted,that in…
