Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)
Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 222
bove the brickwork, to allowfor the usual 1-inch top floor and 2-inch plank beneath, and stillhave a space left for shims to level the floor. PLATE N. GENERAL DRAWING Assembled Parts. Plate N is an example of a plain, everydayshop drawing, to show the relation of parts and the extreme spaceoccupied…
