Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator (1914)

Griffin, Charles Lewis, 1867-, Adams, Charles Clyde, 1882- joint author · Chicago, American technical society · leaf 90

An illustration from Machine drawing; a practical guide to the standard methods of graphical representation of machines, including complete detail drawings of a duplex pump and of a direct-current generator, 1914, leaf 90
Fig. 63. Accurate-Construction for Double V Thread cylinder KL, the diameter of which is equal to the diameter AOminus twice the depth of the thread. Now, on this smaller cylinder,starting at point H, perpendicularly under a point on the line ACwhich is half way from A to C, draw the helix L HJ…
