Machinists' and draftsmen's handbook, containing tables, rules and formulas, with numerous examples explaining the principles of mathematics and mechanics as applied to the mechanical trades; intended as a reference book for all interested in mechanical work (1910)

Lobben, Peder, 1858- · New York, D. Van Nostrand company · leaf 333

An illustration from Machinists' and draftsmen's handbook, containing tables, rules and formulas, with numerous examples explaining the principles of mathematics and mechanics as applied to the mechanical trades; intended as a reference book for all interested in mechanical work, 1910, leaf 333
tial force absorbed in frictionby the collar at a is assumedto be equal to force absorbedby friction in the thread ofthe screw, and may, therefore,be taken from the thirteenthcolumn in the table.Solution: Tangential force per pound at 1 foot radius = 0.0133Tangential force absorbed by friction in… … F = 0.0222 X 5000 = 74 pounds. Example 2. A load of 16,000 pounds rests on a slide and is moved backand forth on a horizontal plane by a screw. The coefficient offriction between slide and plane is 0.1, and the screw shouldnot be loaded with more than 400 pounds per square inch ofprojected area or…
