Machinists' and draftsmen's handbook, containing tables, rules and formulas, with numerous examples explaining the principles of mathematics and mechanics as applied to the mechanical trades; intended as a reference book for all interested in mechanical work (1910)
Lobben, Peder, 1858- · New York, D. Van Nostrand company · leaf 406
—-R fig. fig. 3. swing on their centers; turning the disc a in the direction of thearrow, it will give motion to b, and both discs will move with thesame speed in exactly the same manner as if they were connectedby the strap as shown in Fig. 2. 388 GEAR TEETH. The curve on these two discs…
Mechanical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
