A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 156

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 156 — known as Corn-ish boilers. The gases of com-bustion, after passing throughthe interior of the boiler, passthrough side flues B B aroundthe whole boiler, and also througha flue C beneath the boiler. Large boilers are furnished with parallel fire tubes. Inthe so-called butterfly boiler, the furnace… … Fig. 618.

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
