st-steel uptakes, this system of connection being used for alljoints. There is a steam and water drum above the tubes, connected at eachend, and a mud drum below the tubes, connected at their lower ends. Thewater level is maintained at about the middle of the upper drum. Hand-holes are provided,… … § 403-] STEAM-GENERA TING APPARA TUS. 149 which cause ihe products of combustion to pass between and acioss thetubes three times before reaching the chimney. A view of a battery of these boilers, in use at a sugar refinery in Williams-burgh, N. Y., and rated at 1500 horse-power, is shown in Fig.…
