A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 197
A boiler construction with boiler tubes is also shown inFig. 641. Here A is the steam boiler, separated from theboiler tubes B B by 3. vault D, and the latter are wholly ex- 184 HEAT, STEAM, AND STEAM ENGINES. [§418. posed to the influence of the rearward flowing gases whichcome directly from the… … Between a steam boiler w^ith boiler tubes and one withheating tubes, there is this difference: that in the first thefurnace is situated beneath the tubes, and in the secondbeneath the boiler; consequently, in the first case the gasesflow from the tubes to the boiler, and in the second theyfirst…
Mechanics, Applied · Mechanical engineering
