A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)

Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 237

An illustration from A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc., 1878, leaf 237 — -, bothplates are furnished with disks of vulcanized rubber; andin order that the air may press upon both sides of //, thereis a hole 0 in the lower part of the vessel. The mercuryis filled in by means of a funnel at D. §432.— metal Manometer, or Boiirdon§ Oaug-e.— Bourdons manometer consists of a…

Mechanics, Applied · Mechanical engineering

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
