A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 293
shown in Fig. 711. A is the discharge pipe, which con-ducts the waste steam into the reservoir B C, and D E the Fig. 712. … discharge pipe of the cold-water pipe, which is piercedwith a number of small holes through which the water is § 450.] THE STEAM EXGINE. 2«I forced in jets into B C. Tins water is warmed by thesteam, and most of it passes throiig-h C to the feed pump,which forces it into the boiler. The surphis…
Mechanics, Applied · Mechanical engineering
